The CZ Purlin Roll Forming Machine is designed for producing different sizes of C and Z steel purlins. It is widely used in steel structure workshops, warehouses, industrial buildings, roofing systems, wall support systems, and prefabricated construction projects.
The machine adopts a continuous cold roll forming process and can be customized according to the customer’s profile drawing, material thickness, product dimensions, punching requirements, and target production capacity.
A complete CZ Purlin Production Line can integrate decoiling, feeding, leveling, punching, roll forming, length cutting, and finished product discharge, helping manufacturers improve production automation and maintain stable profile quality.
Zhongtuo can provide standard, automatic, and servo tracking cutting configurations according to different production requirements and market applications.
Main Advantages
- Flexible C/Z Purlin Production
Suitable for producing different specifications of C and Z purlins according to customer requirements. - 1–3 mm Material Thickness
Designed for common steel structure purlin production applications. - PLC Automatic Control
Production length, quantity, speed, and related parameters can be set through the touch screen. - Customized Punching System
Hole position, spacing, quantity, and pattern can be designed according to the customer’s drawings. - Stable Cold Roll Forming
Multiple forming stations gradually shape the steel strip, helping improve dimensional consistency. - Two Cutting Options
Stop cutting and servo tracking cutting systems are available. - Customized Machine Configuration
Voltage, forming stations, profile size range, punching system, and production layout can be customized. - Suitable for Continuous Production
Designed for steel structure factories, purlin manufacturers, and metal profile processing companies.
Reference Parameters
| Item | Specification |
|---|---|
| Product Name | CZ Purlin Roll Forming Machine |
| Finished Product | C Purlin / Z Purlin |
| Material Thickness | 1–3 mm |
| Production Speed | 0–25 m/min |
| Forming Method | Continuous Roll Forming |
| Control System | PLC + Touch Screen |
| Punching System | Hydraulic Punching / Customized |
| Cutting Method | Stop Cutting / Servo Tracking Cutting |
| Raw Material | Galvanized Steel / Steel Coil |
| Voltage | Customized |
| Profile Size | According to Customer Drawing |
| Customization | OEM / ODM Available |
Production Process
Decoiling → Feeding → Leveling → Punching → Roll Forming → Cutting → Finished Product Collection
Installation and Commissioning Service
Before shipment, Zhongtuo carries out machine assembly, testing, and commissioning according to the confirmed profile drawings and technical requirements.
The machine can be tested with suitable material to verify profile dimensions, forming performance, punching accuracy, cutting length, and overall operating condition.
After the equipment arrives at the customer’s factory, we can provide:
- Machine installation guidance
- Equipment commissioning support
- PLC parameter setting assistance
- Operator training
- Forming roller adjustment guidance
- Punching and cutting system adjustment
- Production troubleshooting support
Depending on project requirements, technical support can be provided by remote video guidance or on-site service.
Our goal is to help customers complete installation and start production more efficiently.
After-Sales Service
Zhongtuo focuses not only on machine delivery, but also on long-term production support.
Our after-sales service can include:
- Remote Technical Support
Technical assistance through video, photos, and online communication. - PLC Support
Assistance with PLC parameter checking, control system adjustment, and troubleshooting. - Operator Training
Guidance for machine operation, daily maintenance, and common production problems. - Spare Parts Support
Supply of suitable mechanical, electrical, and wearing parts when required. - Maintenance Guidance
Regular maintenance recommendations according to the actual operating condition of the machine. - Long-Term Technical Assistance
Continuous support after the machine enters normal production.
A responsive technical service system can help customers reduce unnecessary downtime and maintain more stable production.
Factory Testing Before Delivery
Every CZ Purlin Roll Forming Machine is tested before shipment.
The inspection process can include:
- Overall machine operation
- Finished profile dimensions
- C and Z profile forming condition
- Punching position
- Cutting accuracy
- PLC control functions
- Hydraulic system
- Transmission system
- Electrical system
After testing, customers can receive machine running videos, finished profile photos, and relevant test information for confirmation before shipment.
Customer Feedback and Project Experience
Zhongtuo has supplied roll forming equipment to customers in different markets and production environments.
In actual projects, customers usually pay close attention to:
- Finished profile dimensional stability
- Convenience of changing specifications
- Machine operating stability
- Ease of PLC operation
- Technical response efficiency
- After-sales problem-solving capability
Customer feedback from installation and production projects helps us continuously improve machine structure, operating convenience, and control system design.
For Zhongtuo, customer feedback is not only a project evaluation, but also an important reference for improving future CZ Purlin Roll Forming Machine solutions.
Complete Project Service Process
Customer Drawing → Technical Analysis → CAD Confirmation → Machine Manufacturing → Factory Testing → Delivery → Installation & Commissioning → Operator Training → After-Sales Support
From the initial product drawing to machine commissioning, our technical team can participate throughout the project to help ensure that the equipment configuration matches the customer’s actual production requirements.
Application Fields
- Steel Structure Workshop
- Industrial Warehouse
- Roofing Purlin System
- Wall Support System
- Prefabricated Building
- Steel Construction Project
- Metal Building Structure
- Purlin Manufacturing Factory
Why Choose Zhongtuo
Customized Production Solution
Machine configuration can be developed according to profile drawings, steel thickness, punching requirements, production speed, and local electrical standards.
Factory Testing Before Shipment
The equipment is tested and adjusted before delivery to verify machine operation and finished profile quality.
Professional Installation Support
Remote or on-site installation, commissioning, and operator training can be provided according to project requirements.
PLC Technical Support
Technical assistance is available for control system settings, parameter adjustment, and troubleshooting.
Complete After-Sales Service
Support continues after machine delivery, including technical guidance, maintenance assistance, and spare parts service.
International Project Experience
Machine solutions can be adapted to different product standards, voltage requirements, workshop conditions, and production needs in different markets.
